80W Boost Converter 5A Voltage Regulator WZ3605E Programmable Voltage Converter Module LCD Display

Description

• Easy To Read: LCD display can display input and output voltage, output current, output power, output capacity and output time, with accurate readings
• Reverse Connection : The input terminal has against reverse connection, and the reverse connection will not be burnt, and the service life is long. The output terminal has antibackflow function, no need to add antibackflow diode when charging the battery
• Input Voltage: 6-36 (V). Output Voltage: 0.6-36 (V). Output Current: 5A. Output Power: 80 (W): 6-36 (V). Output Voltage: 0.6-36 (V). Output Current: 5A. Output Power: 80 (W)
• Material: material can make sure the durability and stability of the product. Simple structure and professional design, the panel is easy to use with
• Output Switch Setting: In the off state, short press the start button to turn on the output. In the open state, short press the start button to close the output

Specification:
Item Type: Boost Converter
Material: Plastic
Model: WZ3605E
Input Voltage: 6-36 (V)
Output Voltage: 0.6-36 (V)
Output Current: 5A
Output Power: 80 (W)
Output Switch Setting: In the off state, short press the start button to turn on the output. In the open state, short press the start button to close the output
Set the Output Voltage/Current: On the main interface, short press V/ to enter the voltage setting state (reversed in red), press the encoder, move digit by digit to cycle through the selected number, and turn the optional encoder to change the size of the number. After adjustment, press V/ to save the current data and exit. If there is no for 30 seconds, it will automatically exit. In the same way, set the current quickly through A/
M1 and M2 Data Groups are Quickly Recalled: In the main interface, long press V/, data group 1 can be recalled, and the number of the data group that has been recalled will be displayed at the bottom of the status bar of the colleague's screen. In data group 1, long press V/ to return to data group M0. In the same way, long press A/ to perform corresponding operations, and the M3-M9 data group needs to be called and set in the data group setting interface.
Calibration: In the main interface, there is a small current, long press the rotary encoder, you can calibrate the output of the small current.
Interface Switching: When no setting is selected, the rotary encoder performs menu switching

Package List:
1 x Boost Converter
